RE300
15 $
The Cudy RE300 (or similar RE3000/RE1200 models) is a Wi-Fi range extender designed to boost network coverage using wps or a web interface. Plug it near the router, wait for the LED, press WPS on the router and then the extender for 1 second.
Description
| Model Version | RE300 1.0 | |
|---|---|---|
| Memory/Storage | Flash/ROM | 8 MB (64 Mbit ) NOR |
| DDR/RAM | 64 MB (512 Mbit) DDR2 | |
| Wireless | 2.4 GHz Wi-Fi Speed | 300 Mbps |
| 2.4 GHz Wi-Fi Streams | 2T2R (2×2 MIMO) | |
| Wi-Fi Antennas | 2× Fixed | |
| FEM or PA/LNA | 2.4 GHz: 2× Internal | |
| Range Performance | Max: 130 m (427 ft) Tested in open-space environments with minimal interference. Actual WiFi range may vary depending on layout and wall materials. Refer to the Wall Performance specifications for placement suggestions. | |
| Wall Performance | One wooden walls with thickness < 10 cm (4”) One concrete wall with thickness < 10 cm (4”) | |
| Interfaces | 10/100 Mbps RJ45 Ports | 1 |
| Ethernet Notes | 1× LAN Port | |
| LED |
| |
| Physical Buttons |
| |
| Power Input | AC Plug | |
| Power Input Note | EU, US, UK plug are available on corresponding region versions | |
| Power | Power Methods | AC |
| AC | 100V ~ 240V | |
| Reliability | Environment |
|
| Certifications | FCC, CE | |
| Mechanical | Install in a Daisy Chain | Recommend to install less than 3 repeaters in a wireless chain. |
| Installation | Plug-In-Socket | |
| Dimension | 80×60×38 mm 3.15×2.36×1.5 inches | |
| Package Content |
| |
| Ordering Information | Retail Package Dimension | 74×84×107 mm 2.91×3.31×4.21 inches |
| Units per Carton | 60 | |
| Carton Dimension | 40.1×36×34.6 cm 15.79×14.17×13.62 inches | |
